Overhead Chain Conveyors - Technical Data
Overhead Chain Conveyors - Technical Data
Technical specifications for Amber Industries’ MCM overhead chain conveyor range, including Powertrack, Sidetrack and Autotrack systems. The tables below provide model-specific information on conveyor pitch and load capacity, together with downloadable technical data sheets where available.
Powertrack Enclosed Chain Conveyor Systems
| Conveyor Model | Pitch | Load Capacity | Data Sheets |
|---|---|---|---|
| Powertrack 20 | 203mm (8") | 23Kg per pendant |  |
| Powertrack 30 | 229mm (9") | 30Kg per pendant | |
| Powertrack 60 | 229mm (9") | 60Kg per pendant | |
| Powertrack 100 | 406mm (16") | 100Kg per pendant | |
| Powertrack 100S* | 406mm (16") | 100Kg per pendant | |
* Higher chain pull characteristics.
Powertrack Open Chain Conveyor Systems
| Conveyor Model | Pitch | Load Capacity | Data Sheets |
|---|---|---|---|
| Powertrack 90 | 152mm (6") | 91Kg per trolley | |
| Powertrack 200 | 203mm (8") | 200Kg per trolley | |
| Powertrack 500 | 305mm (12") | 500Kg per pendant | |
Sidetrack Overhead Chain Conveyors
| Conveyor Model | Pitch | Load Capacity | Data Sheets |
|---|---|---|---|
| Sidetrack 30 | 229mm (9") | 30Kg per pendant | |
| Sidetrack 60 | 229mm (9") | 60Kg per pendant | |
| Sidetrack 100 | 406mm (16") | 75Kg per pendant | |
Autotrack 'Power & Free' Overhead Chain Conveyors
| Conveyor Model | Load Capacity | Data Sheets |
|---|---|---|
| Autotrack 50 | 50Kg per trolley | |
| Autotrack 100 | 100Kg per trolley | |
| Autotrack 500 | 500Kg per trolley | |
| Autotrack 500S* | 500Kg per trolley |
